Installation
Connecting the Projector
VGA Cable (D-Sub to D-Sub) VGA (D-Sub) to HDTV (RCA) Cable
Audio Cable S-Video Cable
RS-232 Cable Composite Video Cable
USB Cable Internet Cable
1 5
2 6
3 7
4 8
Desktop type Laptop type
4 1
1
1 2
7
3
6 5 2 5
8
„
When connecting cable, power cords of both a projector and external
equipment should be disconnected from AC outlet.
„
The figure above is a sample connection. This does not mean that all of
these devices can or must be connected simultaneously.
„
The cables that come with the projector may differ from the above
illustration. The included cables are based on actual shipment delivery.
