Histogram Area
The Histogram is an interactive control. In the control, you can display events’ time
domain location and the percentage of motion. You can also select a group of events
or a specific period, from the Histogram Area.
5.3.1.3
83B
Control Area
The Control Area contains most of the control selections and toolboxes you need to
browse the database, except Page Control. The Page Control Tool is located on the
bottom-right corner of the Display Area when the program is operating in the event
preview mode (as shown in
X
Figure 5-4
X
). The control tools include: Location Selector,
Period Selector, Playback Method Selector, Jog Dial, Display adjustment, Searching
Range Adjustment, Exporting, and System Control. Details are discussed in Section
X
5.7
X
”
X
Using Tools
X
”.
Figure 5-4 Display By Events (Event Display Mode)
5.3.1.4
84B
Status Area
The Status Area is located at the bottom of the main window. It shows all program
status information, including display mode, display size, display speed, exporting file
Frame Selection Indicator
Page Control
