3-46

Figure 3-28 Layout of the

Monitor tool

Whether you choose the one-camera layout or the four-camera layout, the “Page up”

and “Page down” buttons will be shown in the bottom-left corner of the video area.

You can use these two buttons to switch the pages, as shown in

X

Figure 3-29

X

. Use the

“Page Up” and “Page Down” key in keyboard could also swith the page. Page can be

switched automatically if “Auto switch channel” is enabled. You can specify interval

time and page will be swiched based upon the time.

Figure 3-29 Four-camera Layout

NOTE: Auto-switch function will skip the page that doesn’t contain any channel.

When you want to view one individual camera from the multi-camera layout shown in

1 camera layout

9 cameras layout

6 cameras layout

16 cameras layout

4 cameras layout

13 cameras layout

Switch between cameras

Enable Auto-Switch

Auto-Switch interval (sec.)
