66 © 2008 VBrick Systems, Inc.
Configuration: JPEG
This windows lets you configure a WM encoder with an attached video source (such as a
camera) in order to take JPEG snapshots at a specified interval. Depending on the
application, the snapshot can be displayed in a web page in realtime or FTPed to a server for
archive storage. Type the following URL in a browser to display the captured image in a web
page. The following URL example contains the folder location of the JPEG file for each
encoder (if there are dual encoders).
vbs1
or
vbs2
indicates the slot number of the encoder.
Click
F5
to refresh image.
http://172.22.123.23/vbs1SnapShot.jpg
