Displays the function assigned to the control output terminal.
The screen indications represent the following functions:
• NONE: No function is assigned.
• POWER: Power ON
• SCENE: Scene memory recall
• CH ON: Channel ON
• CH MUTE: Channel mute
• EMG MUTE: Emergency mute activation (All output channel mute)
• PG OUT:
Paging activation
58
C O U T 0 1 I N F - N O N E
(C8) Control output terminal function display
(C9) Control output terminal status display
(when all are open)
C - O U T = _ _ _ _ _ _ _ _ _ _ _ _ C - O U T = 1 2 3 4 5 6 7 8 9 A B C
(C9) Control output terminal status display
(when all are closed)
Status of all control output terminals can be confirmed on the screen, with the terminal Nos. 1 – 12 arranged in
numerical order from left to right.
When closed, the terminal number is indicated by alpha-numerals. Alphabet A represents the terminal number
10, B represents 11, and C represents 12.
An open terminal is indicated by an underscore "_".
Set the type of remote controller connected to the remote control input terminals.
Use the Left and Right shift keys to move the setting items on the screen.
• OFF: Select this setting when no remote controller is connected.
• VOLUME: Select this setting when a normal variable resistor or variable DC power supply unit is connected.
• ZM-9001: Select this setting when the ZM-9001 is connected. This setting adds 6 control inputs. These
inputs are assigned the functions in the setting screens on p. 69-E1 .
• ZM-9002: Select this setting when the ZM-9002 is connected. This setting adds 4 control inputs and 1
remote volume control. These inputs are assigned the functions in the setting screens on p. 69-E1 .
REMOTE 1, REMOTE 2
OFF (default), VOLUME, ZM-9001, ZM-9002
Setting Range Remote Volume Terminal Number
Controller type
(C10) Remote controller type setting
R E M O T E 1 V O L U M E
(C11) Remote-controlled channel setting
(when the remote controller type is set to VOLUME or ZM-9002)
R E M O T E 1 O U T P U T 1
Select the input or output channel of which volume you want to remotely control by using the control input
terminals on the rear panel or ZM-9002's volume control.
The REMOTE 1 on the screen represents the REMT VOL 1 of control input terminal, and the REMOTE 2
represents the REMT VOL 2.
Use the Left and Right shift keys to move the setting items on the screen.
REMOTE 1, REMOTE 2
OFF, INPUT 1 – 8, OUTPUT 1 – 2,
Max. OUTPUT 8 when T-001Ts are used
(default for REMOTE 1: OUTPUT 1, REMOTE 2:
OUTPUT 2)
Setting Range Remote Volume Terminal Number
Remote-controlled channel
