43
G A T E T H R E S H O L D – 3 0
(When the D-001T is used and the gate function is ON)
(A12) Gate threshold level setting
Set the input sensitivity to activate the gate function ( p. 26 ).
–40 to –5 dB (default: –30 dB), 5 dB steps Setting Range
P R E P A G E T O N E – O F F
(A13) Pre-paging tone ON/OFF setting (when the ZP-001T is used)
Set whether or not to sound a one-tone chime before paging.
When set to OFF, the tone does not sound at the paging telephone, either.
ON, OFF (default) Setting Range
(A14) Operation mode setting (when the ZP-001T is used)
M O D E = P A G I N G P O R T
Select the method of activating paging.
• PAGING PORT: Paging is operated if a start signal (no-voltage make signal) is received from the paging
port when the connection between the unit and PABX is established.
• RING SIGNAL: Paging is operated if an IR signal is received when the connection between the unit and
PABX is established. The ZP-001T module functions as a telephone.
PAGING PORT (default), RING SIGNAL Setting Range
A N C A C T I V E
(A15) ANC operation ON/OFF setting (when the AN-001T is used and ANC operation is set to ACTIVE)
Set the ANC operation ( p. 26 ) on or off.
• ACTIVE: Activates the ANC function.
• BYPASS: ANC function does not work.
ACTIVE, BYPASS (default) Setting Range
I N 1 – G A T E – O N
(A11) Gate ON/OFF setting (when the D-001T is used)
Set the gate function ( p. 26 ) to ON or OFF.
• ON: Activates the gate function.
• OFF: The gate function does not work.
ON, OFF (default) Setting Range
