50
11. GATE M
ONO
I
N
/S
TEREO
O
UT
1
This is a versatile gated reverb, ideal for percussive playing. By setting SHAPE to
2 and MIX to 10 (i.e., effect only) you can create a reverse-playback type of sound.
[1] “TIME” 5–500 [ms] Sets the gate time.
[2] “LODAMP” 0.0–10.0 * Adjusts the attenuation of the low-frequency range.
[3] “HIDAMP” 0.0–10.0 * Adjusts the attenuation of the high-frequency range.
[4] “PREDELAY” 0–100 [ms] Sets the initial delay before the reverberation begins.
[5] “SHAPE” 1,2
Sets the type of gate.
1: Conventional gate.
2: Reverse-playback type gate.
[6] “MIX” 0.0–10.0 * Adjusts the mix balance between the reverb
sound and direct sound. With a setting of 10 you
will hear only the reverb sound.
Mono In / Mono Out 1
Mono In / Stereo Out 1
Mono In / Mono Out 2 Mono In / Mono Out 3
Mono In / Stereo Out 2
Stereo In / Stereo Out 1 Stereo In / Stereo Out 2 Stereo In / Stereo Out 3
