4
Configuration
Figure 1 illustrates the basic configuration of the KVM system.
Figure 1 The KVM system configuration
Figure 2 shows the front of the 16 port KVM (Model B072-016-1). The 8 port version
(model B072-008-1) is the same but with only 8 sets of LEDs.
Figure 2 NetCommander KVM front panel
Figure 3 shows the rear of the 16 port KVM (Model B072-016-1). The 8 port version (model
B072-008-1) is the same but with only 8 computer ports.
Figure 3 NetCommander KVM rear panel
Front Panel
Rear Panel
SIU = Server Interface Unit
