TD - Series
- 20 -
TD Series Digital Solid State Soft Starter 48 - 1250A
5.4.10 Fault History and Run Time
5.5 Function Descriptions
The unit is set at the factory with typical starting characteristics that perform well
in most applications.
Note: Customer must program motor FLA (F001) for unit to operate.
5.5.1 Motor and Overload Function Descriptions
F001 = Motor FLA
Factory Setting = 0
Range = 50 - 100% of Unit Max. Current.
Set the value of this function to the motor nameplate Full Load Amps
(FLA). Adjustments for service factor are not necessary when
programming this function. (See note below). If the motor nameplate
FLA is not available, use typical values as shown in NEC, NEMA
standard MG-1 or other reputable third party source (motor manufacturer,
etc.).
Note: To prevent adjusting the settings beyond the starter Max Amp rating, the range
of adjustment for the Motor Nameplate FLA will vary to reflect the Service
Factor as programmed into F002. At the default setting of 1.0SF, the full range
of adjustment from 50 - 100% of the Max Amp rating is available. For example
F002 = 1.15 to reflect a 1.15SF, the maximum FLA programmable into F001 will
be limited to 85% of the starter Max. Amp rating (100% - 15%).
Fn Group Function
Adjustment
Range
Setting
Increments
Factory
Setting
Section
F075 Fault History #1, Latest Fault
0, 1 - 27 (Fault #: see Fault
code list; 0: No fault history)
View Only 0 5.5.10
F076 Time Stamp, Fault #1
00.00-23.59 (hh.mm)
[hh = 00-23; mm = 00-59]
View Only 00.00 EST 5.5.10
F077 Date Stamp, Fault #1
01.01 - 12.31 (MM.DD)
[MM = 01-12; DD = 01-31]
View Only 01.01 5.5.10
F078
Fault History #2,
Previous Fault 0, 1 - 27 (Fault #: see Fault
code list; 0: No fault history)
View Only 0 5.5.10
F079 Time Stamp, Fault #2
00.00-23.59 (hh.mm)
[hh = 00-23; mm = 00-59]
View Only 00.00 EST 5.5.10
F080 Date Stamp, Fault #2
01.01 - 12.31 (MM.DD)
[MM = 01-12; DD = 01-31]
View Only 01.01 5.5.10
F081 Fault History #3, Oldest Fault
0, 1 - 27 (Fault #: see Fault
code list; 0: No fault history)
View Only 0 5.5.10
F082 Time Stamp, Fault #3
00.00-23.59 (hh.mm)
[hh = 00-23; mm = 00-59]
View Only 00.00 EST 5.5.10
F083 Date Stamp, Fault #3
01.01 - 12.31 (MM.DD)
[MM = 01-12; DD = 01-31]
View Only 01.01 5.5.10
F084 Run Time, Hours 000.0 - 999.9 (hours) View Only 0 5.5.10
F085 Run Time, K Hours 0000 - 9999 (thousand hours) View Only 0 5.5.10
F086 Run Counts 0000 - 9999 (times) View Only 0 5.5.10
F087 Run Counts, 10K times 0000 - 9999 (10 thousand times) View Only 0 5.5.10
Fau
lt H
istor
y and R
un Ti
me
