1800 Series Single Phase Uninterruptible Power Systems
Product Specifications – Rev 3.0 August 2008
2.4 kVA
Page 4 of 6
8.0
System Status and Control Indicators
8.1
Panel
The UPS has a panel on the front for complete monitoring control of UPS.
Operation
panel
features:
1)
Run/Stop
button
2)
AC input voltage indicator
3)
Inverter
status
indicator
4)
Alarm
indicator
5)
Fault
indicator
6)
LED
Warning
messages:
1)
Low
Battery
2)
Current
limit
3)
Ambient
Over
Heat
4)
Battery
Over
Heat
5)
Input
Over
Voltage
6)
Input
Frequency
Regulation
7)
Output
Overload
Fault
Messages:
1)
Replace
Battery
2)
Battery
Shutdown
3)
DC Bus Over Current
4)
DC Bus Over Voltage
5)
DC
Bus
Imbalance
6)
Output
Under
Voltage
7)
Output
Over
Voltage
8)
System
Over
Heat
9.0 Dimensions
Tower
1.5 kVA 2.0
kVA
2.4
kVA
Weight
170
lbs
170
lbs
170
lbs
Width
10”
10”
10”
Depth
27”
27”
27”
Height
23.5”
23.5”
23.5”
10.0 Communications
10.1
Dry Contact Communication
The remote interface is a standard feature. Signals are available through a DB9 male
connector.
