MM23772, Rev. B
70
8.23.2 Sending an Individual Call
8.23.2.1 Pre-Stored Individual Calls
The following procedures describe how to initiate and complete a Pre-Stored Individual Call.
System Model Radio:
1. To select a pre-stored individual phone number, enter the individual call mode using the  key. is
displayed. Then scroll through the list of stored numbers using the  or  key.
2. Press the PTT button; when the radio is clear to transmit, turns ON, turns OFF and the channel
access tone sounds. Line one shows the called individual's name if found in the list of stored
individuals or LID followed by the logical ID number of the unit being called. The message
*INDV*
displays on line two.
Scan Model Radio:
1. To select a pre-stored individual number, enter the menu mode by pressing the  key. Scroll through
the mode list using the  or  key.
2. Press  . is displayed. Scroll through the list of stored phone numbers using the  or  key until
the desired number is displayed. Press  .
3. Press the PTT button; when the radio is clear to transmit turns ON, turns OFF and the channel
access tone sounds. Line one shows the called individual's name or LID. The message
*INDV*
displays on line two.
8.23.2.2 Direct Dial Individual Calls (System Model Only)
1. The following procedure describes how to initiate and complete a Direct Dial Individual Call.
2. The individual call ID is not stored in the pre-stored list of call IDs but the individual unit ID is
known, it can be entered directly from the keypad.
3. Press and hold the PTT button to transmit. will turn ON, will turn OFF, and the channel access
tone will sound. Line one shows the called individual's ID followed by the logical ID number of the
unit being called. The message
*INDV* displays on line two. Proceed talking into the microphone.
8.23.3 Call Storage Lists
There are two lists available for call storage in the P7200 series radios, the calls received list (1 - 10) and
the personality list (1 - 99 as defined by the user). When the individual call mode is entered by pressing
 , the calls received list is available. The user can toggle to the personality list by selecting any index
other than 0 or toggle between the two lists by pressing the  key. If wrap is enabled, the calls received
list wraps on itself and not into the other list.
