MM23772, Rev. B
32
7.11 BASIC MENU STRUCTURE
Table 7-4 illustrates the basic P7200 OpenSky menu structure. Menu items will vary depending upon
system programming, radio hardware, and optional configurations. All menus except the dwell display
menu can be turned off by network administration personnel.
Table 7-4: Basic P7200 OpenSky Menu Structure
Menu Name
Radio Displays
(first and second lines)
Usage Notes
To/From Dwell Display
 
registration, RF sync and
transceiver status codes
Engineering Display
(Menu may not be available
per programming.)
bit-error rates
and RSSI data
Displays radio system connection data. For engineering use.
 
OFF/ON
Silent Emergency
“SilentEmerg”
Use  or  to toggle between OFF/ON. Press  to enable.
 
available modes
Operating Mode
(e.g., OTP, OCF) “Mode Menu”
Use  or  to choose an available mode. Press  and
confirm (Y/N) with  or  and  again.
 
current latitude and longitude
(degrees:minutes:seconds)
GPS Fix
[e.g., GPS, GPS (Site), GPS
(Aged)] “GPS”
GPS latitude and longitude position of currently tuned-to
base station [“GPS (Site)”] or V-TAC (“GPS”) scrolls across
top line of the display. “GPS (Aged)” indicates VTAC
coordinates haven’t been updated for more that 2 minutes.
 
User ID # of user currently logged
in User ID
“User ID”
User’s identification/name scrolls across top line of the
display (if programmed).
 
Radio’s IP address
IP Address
“IP Address”
Radio’s Internet Protocol (IP) address scrolls across top line
of the display.
 
station’s call sign
Station Identification
“Station ID”
Station’s identification/name scrolls across top line of the
display (if programmed).
 
“OFF” Stealth Mode
(display backlight is disabled) “StealthMenu”
Use  or  to turn on. Press any button to turn it off.
 
“LOW”, “MEDIUM”, “MEDHIGH”,
“HIGH” Treble Level
“Treble Menu”
Use  or  to choose speaker treble level. Press  to
return to dwell display.
 
“<< >>”
Display Brightness
“Bright Menu”
Use  or  to brighten or dim backlighting. Press  to
return to dwell display.
 
“OFF”, “LOW”, “MED”, HIGH”
Side Tone Level
“Side Menu”
Use  or  to choose side tone level. Press  to return to
dwell display.
 
selected channel Selected Channel
(Menu may not be available
per radio programming)
“ChannelMenu”
Displays the current channel. Press  to return to dwell
display.
 
See Next Page
