Example 2. Set Read/Write Parameters, Enter Data, Encode
Stripe, and Eject:
Command Result
“&D”1”75↵ Sets track-1 density to 75 bpi
“&D”3”75↵ Sets track-3 density to 75 bpi
“&CDEW”1”a3↵ Sets to encode track 1 with 5-bit
characters
“&CDER”1”q3↵ Sets to read 5-bit characters on track
1
“&B”1”12345↵ Enters 12345 in track-1 buffer
“&B”2”54321↵ Enters 54321 in track-2 buffer
“&B”3”09876↵ Enters 09876 in track-3 buffer
“&E*↵
Encodes three tracks using buffer
data, and positions card for printing
“ME↵ Ejects card from printer
Example 3. Reset to ANSI/ISO:
Command Result
“&CDEW”1”A↵ Resets track-1 encodes to ANSI/ISO
std.
“&CDER”1”Q↵ Resets track-1 reads for ANSI/ISO
std.
“&CDEW”2”B↵ Resets track-2 encodes to ANSI/ISO
std.
“&CDER”2”R↵ Resets track-2 reads for ANSI/ISO
std.
“&CDEW”3”C↵ Resets track-3 encodes to ANSI/ISO
std.
“&CDER”3”S↵ Resets track-3 reads for ANSI/ISO
std.
54
980179-001 Rev. A
Magnetic Card Stripe Encoder
