SmartPro line interactive UPS system is ideal for voice, data, medical and industrial networking applications
High 96% line-power efficiency rating reduces energy consumption and BTU heat output
Line interactive Automatic Voltage Regulation (AVR) offers two levels of voltage boost during brownouts and one level of voltage cut during
overvoltages
Maintains continuous operation through blackouts, voltage fluctuations and surges
Corrects line voltage conditions as low as 83V and as high as 145 back to 120V nominal values
Standard internal battery set offers 12 minutes at full load and 4 minutes at full load
Optional BP48V24-2U and BP48V60RT3U external rack/tower battery packs enable extended runtime operation
Compact form factor installs using only 2 rack spaces (2U) with a maximum installed depth of only 19 inches
Ships with all mounting accessories for 4 post rackmount installation
Optional 2POSTRMKITWM enables 2 post rackmount or wallmount installation
Optional 2-9USTAND accessory enables small-footprint upright tower placement
Network interfaces support simultaneous communications via built-in USB, DB9 serial and SNMPWEBCARD slot
HID compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X
Included PowerAlert UPS monitoring software supports safe unattended shutdown, monitoring and control via local connected servers, with
the built-in ability to shutdown any number of additional servers over IP
UPS interface supports on-battery, low-battery, power-restored, AC-voltage, DC-voltage, output current monitoring, battery charge current,
battery capacity, AC line frequency, timed inverter sutoff, activate self-test, load bank output power control and remote reboot
Built-in Emergency Power Off (EPO) interface with cable
Factory installed NEMA 5-20P input plug; user configurable L5-20P or L5-30P input plug-in connections supported
NEMA 5-15R, NEMA 5-15/20R and L5-20R output receptacles
Integrated 3 bank switched PDU enables remote outlet management for load shedding or remote reboot of individual load banks (1 outlet
per load bank)
Front panel LEDs offer current monitoring and battery charge level information
UPS ships fully assembled in full compliance with DOT regulations, no time consuming connection of internal batteries by user required
2 year manufacturer's product warranty, $250,000 ULtimate Lifetime Insurance
Specifications
SYSTEM OVERVIEW
Voltage compatibility 120 VAC
Frequency
compatibility 60 Hz
OUTPUT
Output VA 2600
Output watts 2100
Output nominal
voltage 120V AC
Output voltage
regulation LINE MODE: Sine wave line voltage 120V (-18% / +8%), BATTERY MODE: Sine wave output 120V +/-5%
Output frequency
regulation LINE MODE: Passes line frequency of 60Hz +/-10%, BATTERY MODE: Inverter output regulated to 60Hz +/-0.5Hz
Outlet quantity / type 4 5-15R, 4 5-15/20R and 1 L5-20R
Customized load
management
receptacles 3 individually controllable outlets support load shedding and remote reboot on demand of locked network devices.
Controllable via PowerAlert software to switch off optional loads, like monitors, to increase available runtime for servers
and other critical devices
Overload protection Resettable circuit breaker
INPUT
Maximum input amps 16A with 5-20P or user installed L5-20P input plug / 24A with L5-30P user installed input plug
Input connection type 5-20P (user installed L5-20P and L5-30P input plugs supported)
Input cord length 10 ft., 10 gauge
Recommended
Electrical Service 20-30A 120V
BATTERY
