Transition Networks CETTF10XX-200 - Manual

Installation . . . . . . . . . . . . . . . . . .2
Operation . . . . . . . . . . . . . . . . . . .5
Cable Specifications . . . . . . . . . . .7
Technical Specifications . . . . . . . .9
Troubleshooting . . . . . . . . . . . . .10
Contact Us . . . . . . . . . . . . . . . . .11
Compliance Information . . . . . . .12
User’s Guide
CETTF10xx-200
Slide-in-Module Media Converter
• Ethernet
• Copper to Fiber
• 10Base-T to 10Base-FL
Transition Networks CETTF10xx-200 series Ethernet
10Base-T to 10Base-FL media converters (designed
to be installed in a PointSystem™ chassis) connect
10Base-T twisted-pair copper cable to multimode or
single mode 10Base-FL fiber-optic cable.
* Typical maximum cable distance. Actual distance is dependent upon the
physical characteristics of the network installation.
Part Number Port One - Copper
10Base-T Port Two - Fiber-Optic
10Base-FL
CETTF1011-200 RJ-45
100 m (328 m)*
ST, 850 nm multimode
2 km (1.2 miles)*
CETTF1012-200 RJ-45
100 m (328 m)*
ST, 1310 nm single mode
20 km (12.4 miles)*
CETTF1013-200 RJ-45
100 m (328 m)*
SC, 850 nm multimode
2 km (1.2 miles)*
CETTF1014-200 RJ-45
100 m (328 m)*
SC, 1310 nm single mode
20 km (12.4 miles)*
CETTF1022-200 RJ-45
100 m (328 m)*
ST, 1310 nm single mode
40 km (24.9 miles)*
CETTF1027-200 RJ-45
100 m (328 m)*
ST, 1300 nm multimode
5 km (3.1 miles)*
