Tektronix PHASER 740L - Manual (Page 22)

20 Front Panel Messages
Message Action Page
:low The displayed color Toner Cartridge is running out; replace it soon.
Energy Star Mode
Wake Up Menu The printer is in energy conservation mode. Press the Wake Up button on the front panel or send a print job
to bring the printer to Ready .
Error XX 1 Press the Info button for problem information. Follow any steps listed.
2 If the failure persists, note the display’s error number.
3 Look up the error number in the online topic “Error Codes” on the printer’s CD-ROM or the web site at
www2.tek.com/merlin/tko .
Fuser:replace Replace the Fuser soon.
Fuser Roll:replace Replace the Fuser Roll soon.
Imaging Unit:replace Replace the Imaging Unit soon.
Jam at
Open A media jam has occurred at the indicated location. The second line of the message indicates the location
of the jam. 26
Main Charge Grid:replace Replace the Main Charge Grid soon.
Media Tray:empty Refill the media tray. If your printer has a Lower Tray Assembly, the choices include Upper, Middle, or Lower. 7
MPT:
<--- ---> OK Media has been loaded in the Multi-Purpose Tray; select that media type in the front panel. Press the arrows
to scroll to the appropriate media type; press
OK . The printer waits a minute for you to select a media type at
the front panel prompt. After a minute, the job prints, using the previously selected media type.
8
Stopped:
Fuser Roll:replace Replace the Fuser Roll now .
Stopped: replace The displayed color Toner Cartridge is empty; replace it now .
Transfer Kit:replace Replace the Transfer Kit (transfer roller and waste bin) soon.
