TANDBERG 6000 MXP - Manual (Page 208)

D1335504_T6000_MXP_User_Manual
198
The Server Address is the manually configured address for the outbound proxy and registrar. It is
possible to use a fully qualified domain name, or an IP address. The default port is 5060 for TCP
and UDP, but another one can be provided.
Server Address:
Examples:
“
sipserver.example.com
”
“
sipserver.example.com:5060
”
“
10.0.0.2
”
“
10.0.0.2:5061
”
Authentication
User Name
This is the user name part of the credentials used to authenticate toward the SIP Server.
User name:
Password
This is the password part of the credentials used to authenticate toward the SIP Server.
Password:
