5
SRC-2X Installation and Operation Manual
SETUp CONT’D
Dipswitch 4 ON, (Dipswitch 3 OFF) = String mode Only read on power up or
reset Inputs 1 and 2 may be programmed to output a data string when closed. To
enter program mode, enter a “P” from a terminal program. The following will be
displayed:
INPUT DATA STRING ENTRY
Enter a 1 or 2, then the string data you want to be transmitted when the correspon-
ding input is closed. To enter a HEX character, enter a “/” followed by the hex value.
For example, if you want to send 12345(CR/LF) for input 2, enter: 212345/0D/0A
and hit the ENTER key to terminate. Up to 48 characters can be entered for each
input.
NOTE: /0D counts as three characters.
OUTPUT 1:
(Non-volatile string data that will be outputted when input 1 is activated).
OUTPUT 2:
(Non-volatile string data that will be outputted when input 2 is activated).
RELAY COMPARE DATA ENTRY
Enter a 3 or 4, then the string data that when received, will cause relays 1 and/or 2
to pulse for one second. The SRC-2X will receive and store whatever data it
receives from the serial port, whether it be ASCII or HEX and use that to compare
against incoming data. Up to 16 characters may be entered for each relay.
INPUT 1:
(Non-volatile input string data that when received and compared will pulse relay 1)
INPUT 2:
(Non-volatile input string data that when received and compared will pulse relay 2)
