Transition Networks CBFTF10XX-15X - Manual (Page 5)

8
CBFTF10xx-15x
Tech Support: 800-260-1312 International: 952-941-7600 7am-6pm CST (GMT-6:00)
CABLE SPECIFICATIONS
The physical characteristics must meet or exceed IEEE 802.3™ specifications.
Fiber Cable
Bit Error Rate: <10-9
Singlemode fiber (recommended): 9 µm
Multimode fiber (recommended): 62.5/125 µm
Multimode fiber (optional): 100/140, 85/140, 50/125 µm
CBFTF1011-150, CBFTF1013-150 multimode
Fiber Optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm
Fiber Optic Receiver Sensitivity: min: -30.0 dBm max: -14.0 dBm
Link Budget: 11.0 dB
CBFTF1014-150 singlemode
Fiber-optic Transmitter Power: min: -15.0 dBm max: -8.0 dBm
Fiber-optic Receiver Sensitivity: min: -31.0 dBm max: -8.0 dBm
Link Budget: 16.0 dB
CBFTF1015-150 singlemode
Fiber-optic Transmitter Power: min: -8.0 dBm max: -2.0 dBm
Fiber-optic Receiver Sensitivity: min: -34.0 dBm max: -7.0 dBm
Link Budget: 26.0 dB
CBFTF1018-150 multimode
Fiber-optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm
Fiber-optic Receiver Sensitivity: min: -30.0 dBm max: -14.0 dBm
Link Budget: 11.0 dB
CBFTF1029-150, CBFTF1029-151 singlemode
Fiber-optic Transmitter Power: min: -13.0 dBm max: -6.0 dBm
Fiber-optic Receiver Sensitivity: min: -32.0 dBm max: -3.0 dBm
Link Budget: 19.0 dB
CBFTF1029-152, CBFTF1029-153 singlemode
Fiber-optic Transmitter Power: min: -8.0 dBm max: -3.0 dBm
Fiber-optic Receiver Sensitivity: min: -33.0 dBm max: -3.0 dBm
Link Budget: 25.0 dB
Copper Cable Maximum Cable Distance: 100 meters
Category 3: (May be used for 10 Mb/s operation)
Gauge
24 to 22 AWG
Attenuation 11.5 dB/100m @ 5-10 MHz
Category 5: (REQUIRED for 100 Mb/s operation)
Gauge
24 to 22 AWG
Attenuation 22.0 dB /100m @ 100 MHz
• Straight-Through Twisted-Pair cable must be used.
• Shielded Twisted-Pair (STP) OR Unshielded Twisted-Pair (UTP) may be used.
• Pins 1&2 and 3&6 are the two active pairs in an Ethernet network .
• Use only dedicated wire pairs for the active pins:
(e.g., blue/white & white/blue, orange/white & white/orange, etc.)
• Do not use flat or silver satin wire.
1
2
3
6
Straight-Through Cable
Twisted Pair #1
Twisted Pair #2
1
2
3
6
[email protected] -- Select the “Transition Now” Link for a Live Web Chat 9
TECHNICAL SPECIFICATIONS
For use with Transition Networks Model CBFTF10xx-15x or equivalent.
Standards IEEE 802.3™
Data Rate: 10 Mb/s, 100 Mb/s
Dimensions 3.4" x 4.7" x 0.87" (86 mm x 119 mm x 22 mm)
Weight 4 oz. (114 g) (approximate)
Power Consumption: 4.0 W
MTBF 629,677 hours (MIL217F2 V5.0) (MIL-HDBK-217F)
1,630,181 hours (Bellcore7 V5.0)
Packet Size: Unicast MAC address: 128K bytes (1 Mbit)
Maximum packet size: 1522 bytes
Memory: 1K bytes
Environment Tmra*: 0 to 60°C (32 to 140°F )
Storage Temp: -20 to 85°C (-4 to 185°F )
Humidity 10-90%, non condensing
Altitude 0-10,000 feet
Warranty Lifetime
*Manufacturer’s rated ambient temperature: Tmra range for this Slide-In-Module
depends on the physical characteristics and the installation configuration of the
Transition Networks PointSystem™ chassis in which this Slide-In-Module will be
installed.
Product is certified by the manufacturer to comply with DHHS Rule 21/CFR,
Subchapter J applicable at the date of manufacture.
CAUTION: Visible and Invisible Laser Radiation When Open. Do Not Stare
Into Beam Or View Directly With Optical Instruments.
CAUTION: Use of controls, adjustments or the performance of procedures
other than those specified herein may result in hazardous radiation exposure.
