72
Appendix II: Cable Connection
Tables
SAS / SATA Cables
Power Supply Cables
Table 1: B5381(with LSI SAS controller)
M1210 Adapter Board Connect to Motherboard
SAS 1 (J21) Æ SAS Connector
(SAS2)
SAS 2 (J22)
SAS 3 (J23)
SAS 4 (J24)
Table 2: B5381 (without LSI SAS controller)
M1210 Adapter Board Connect to Motherboard
SAS 1 (J21) Æ SATA Connector (J8)
SAS 2 (J22)
SAS 3 (J23)
SAS 4 (J24)
Table 3: Power Supply to Motherboard
Power Supply Connect to Motherboard
P1 24-pin power cable Æ CN5 24-pin connector
P2 8-pin power cable Æ CN6 8-pin connector
