Magnetic Stripe Reader
No device are needed.
Testing the USB MSR Keyboard Emulation
1
Plug in the device.
2
Open MS Word.
3
Slide the card through the MSR to view the data.
Testing the USB-HID Class MSR
1
On the CD, browse to Touch Monitor Peripherals\Magnetic Stripe Card
Readers\Demo.
2
Open the Readme.txt and follow instructions to test the unit.
Convert MSR from HID to keyboard emulation
MSR Convertion:
Get program @ http://www.magtek.com/support/software/demo_programs/usb_swipe_insert_reader.asp
1. To convert from HID to Keyboard Emulation Mode
.
1.1
Double click on HID MSR Icon in desktop.
The following window will appear
1.2
Click on About to verify version
1.3
Close About Dialog box.
1.4
Click on Read Cards…
