SecuGen _______________________________________________________ Products - 4
PC Peripheral Type,
USB Fingerprint Recognition Device
FDU02
SGD 03-03210001A
SecuGen FDU0
2
Connector Pin Description
Name
No
States
Description
GND
1
Power
Sensor Ground
CLK
2
Input
Sensor Clock
SDATA0
3
Output
Sensor Data0
SDATA1
4
Output
Sensor Data1
SDATA2
5
Output
Sensor Data2
SDATA3
6
Output
Sensor Data3
DA
7
Input
Sensor DA
CL
8
Input
Sensor CL
VCC
9
Power
Sensor VCC (DC +5V)
Table 1 JP1 Pin Description
Name
No
States
Description
VCC
1
Power
VCC (DC +5V)
USB_A
2
I/O/Z
USBD -
USB_B
3
I/O/Z
USBD +
GND
4
Power
Ground
SHIELD
5
Power
Shield
Table 2 J1 Pin Description
Name
No
States
Description
GND
1
Power
Ground
PS/2 CLK
2
I/O
PS/2 CLOCK
PS/2 DATA
3
I/O
PS/2 DATA
VCC
4
Power
VCC (DC +5V)
WAKEUP
5
Input
Mouse wake-up
N.C
6
N.C
Reserved
OUT_VCC
7
Power
Controlled VCC (DC +5V)
Table 3 JP2 Pin Description
