1229L Multifunction 12" LCD Desktop Touchmonitor (3000 Series)

The 1229L multifunction touchmonitor may be ordered with up to three integrated peripherals, including
an ergonomically-placed magnetic stripe reader (MSR), biometric fingerprint recognition device, and a
rear-facing customer display. All are incorporated into the monitor housing and designed to flow with its
elegant styling. Available with a choice of touch technologies, the 1229L is fully configurable for a variety
of applications in the retail, hospitality, medical, gaming, and amusement markets where its compact
design efficiently saves valuable work space as well as minimizing connections.

Features

z

Higher brightness, better contrast, and wider viewing angle than most 12" LCDs

z

"Designed for touch" features such as a stable tilt base

z

Available with

AccuTouch Five-Wire Resistive Technology

(activated with fingernails, gloves,

credit cards, or any stylus) or, for the ultimate in optics,

IntelliTouch Surface-Wave Technology

,

Surface Capacitive Technology

or

CarrollTouch Infrared Technology

z

Optional ergonomic 3 stripe MSR

available in three versions: USB with keyboard emulation; USB

with human interface driver (HID) class specification 1.1; and serial, which supports OPOS.
OPOS is only supported in serial version

z

Optional rear-facing customer display

z

Optional biometric fingerprint recognition device

z

Integrated USB hub with two available USB connections. Also allows a single USB cable to carry
the touch signal, MSR and fingerprint data, and output to the customer display. The serial version
has cables/external connectors to carry the touch and MSR data.

z

Single power supply for all optional devices

z

Cables hidden from user's view

z

Built-in speakers located in display head

z

Multilingual on-screen display (OSD) with extras including speaker volume, treble, bass, and
balance

z

Mounting holes on base bottom for tabletop security

z

Base removable,

VESA mounting

option

z

Controls on the side rather than the front, plus lockout function for public use

z

Sealed touchscreen; CarrollTouch version features a seamless watertight seal due to its unique
co-molded construction

z

Diagnostic LEDs for touch and video

z

Long-lasting product cycle

z

Worldwide agency approvals

Specifications

Model

1229L

Series

3000

Availability

Worldwide

Case/bezel color

Dark gray

Display

Size: 12.1" diagonal
Type: Active matrix TFT LCD
Aspect ratio: 4 x 3

Useful screen
area

Horizontal: 9.69" (246 mm)
Vertical: 7.27" (184.5 mm)

Monitor
dimensions

Width: 13.9" (353 mm)
Height (inc. base): 11.6" (295 mm)
Depth (inc. base): 11.8" (300 mm)
