33
Section 13 : Optional Accessories
LA-D302 Balanced Amplifier Kit WR-7000 Sync Cable
When using more than one DA-302, connect this cable to
the EXT CONTROL connectors. (
úp.26)
Specifications
Analog input connector (XLR-3-31 type x 2) (#2 hot)
Reference input level:
+4 dBu, balanced (FS -16 dB)
Input impedance: More than 10 kohms
Analog output connector (XLR-3-32 type x 4) (#2 hot)
Reference output level:
+4 dBu, balanced (FS -16 dB)
Maximum output level: +20 dBu, balanced
Output impedance:
75 ohms (load of more than 600 ohms)
