13
Section 4 : Features and Controls
4-2. Rear panel
z ANALOG (UNBALANCED) connectors
IN (L, R):
Analog input connectors for Deck 1.
·During dual recording or continuous recording,
these connectors are used as the input connectors
common for Deck 1 and Deck 2.
OUT 1 (L, R):
Analog output connectors for Deck 1.
OUT 2 (L, R):
Analog output connectors for Deck 2.
CASCADE OUT (L, R):
When more than one DA-302 is used, output analog
signals from these connectors. (
úp.26)
·To select signals for output, refer to "Cas Out" on
the menu. ( úp.28)
x DIGITAL connectors
INPUTS (1, 2):
Digital input connectors for Deck 1 and Deck 2.
OUTPUTS (1, 2):
Digital output connectors for Deck 1 and Deck 2.
CASCADE OUT:
When using more than one DA-302, output digital
signals from this connector.
·To select signals for output, refer to "Cas Out" on
the menu. ( úp.28)
c
EXT CONTROL connectors
Use when connecting more than one DA-302 using the
optional WR-7000 connection cable. (
úp.26)
v
REMOTE IN connector
Connect the provided RC-D302 remote control unit.
