2-2
2. SPECIFICATIONS EO1-33017
2.2 OPTION
■ Auto Ribbon Saving Mode
NOTES: 1. To activate ribbon saving function at a speed of 8"/sec., the no print area should extend
more than 25 mm.
2. Depending on the relationship between the outer diameter of rewound ribbon and print
speed, ribbon usage may vary as follows:
Print speed Ribbon loss
3"/sec Approx. 5 mm
4"/sec Approx. 10 mm
8"/sec Approx. 23 mm
2.2 OPTION
Description
A stop and cut swing cutter
This module strips the label from the back-
ing paper with the take-up block and strip
block.
This board enables the following PCMCIA
cards to be used.
* LAN card: 3 COM EtherLink
® III (recom-
mended)
* ATA card: Conforming to PC card ATA
standard
* Flash memory card: 4MB card
(See Page
10-1.)
Option Name
Cutter module
Strip module
PCMCIA interface
board
Type
B-4208-QM
B-4908-H-QM
B-8700-PC-QM
Operation Panel setting.
Source
See NOTE 1.
See NOTE 1.
See NOTE 1.
NOTES: 1. Available from your nearest TOSHIBA TEC representative or TOSHIBA TEC Head
Quarters.
Auto ribbon saving function is activated by Parameter Settings (Refer to your authorized
TOSHIBA TEC representative) and none print area extends for more than 20 mm.
3. Please contact your authorised TOSHIBA TEC representative to change the
