Toshiba B-880-QQ SERIES - Manual (Page 7)

2-1
2. SPECIFICATIONS EO1-33017
Supply voltage Universal (automatic switching)
85-138 V, 50/60 Hz
187-276 V, 50/60 Hz
Be sure to use a power cord which meets the standard.
Power consumption 3.5 A, 260 W maximum (standby: 360 mA, 20 W maximum)
Operating temperature 5˚C ~ 40˚C
range
Relative humidity
25% ~ 85%RH (no condensation)
Print head Thermal print head 12 dots per mm (305 dots per inch)
Printing methods Thermal direct or Thermal transfer
Print speeds 76.2 mm/sec. (3 inch/sec.), 101.6 mm/sec. (4 inch/sec.),
203.2 mm/sec. (8 inch/sec.) When the media width is 160 mm or less.
Maximum print width 213.3 mm (8.40 inches)
Dispensing modes Batch (Continuous), Strip (On-demand) and Cut modes
(Both cut and strip modes are available only when their respective modules
are fitted.)
Message display 20 characters x 1 line
Dimensions 437 mm (width) x 282 mm (depth) x 395 mm (height)
Weight
Available bar-code types
JAN8, JAN13, EAN8, EAN8 + 2 digits, EAN8 + 5 digits
EAN13, EAN13 + 2digits, EAN13 + 5 digits
UPC-E, UPC-E + 2 digits, UPC-E + 5 digits
UPC-A, UPC-A + 2 digits, UPC-A + 5 digits
MSI, ITF, NW-7, CODE39, CODE93, CODE128
EAN128, Industrial 2 to 5, Customer Bar Code, POSTNET, KIX CODE,
RM4SCC (ROYAL MAIL 4STATE CUSTOMER CODE),
Two-dimensional code
Fonts
Times Roman (6 sizes), Helvetica (6 sizes), Presentation (1 size),
Letter Gothic (1 size), Prestige Elite (2 sizes), Courier (2 sizes),
Rotations 0˚, 90˚, 180˚, 270˚
Standard interfaces Serial interface (RS-232C)
Parallel interface (Centronics)
Expansion I/O interface
Optional interface PCMCIA interface
2. SPECIFICATIONS
2.1 PRINTER
2.1 PRINTER
Item
Model
∗
Data Matrix TM is a trademark of International Data Matrix, Inc.
PDF417 is a trademark of Symbol Technologies, Inc.
Data Matrix, PDF417, QR Code, Maxi Code, Micro PDF417
B-882-QQ
26 kg (without media and ribbon)
OCR (2 types), Writable characters (40 types, 2-byte character available),
Outline font (4 types), Price font (3 types)
