9

S1472-001-01 http://www.tyan.com

ATX/AT Power Supply Select:

J14 J15 J16 J17 J18 J19 J33 J53 J54 J55

Default ATX on off off off on on off off off off

AT on off off off on on on on off on

P55C Pentium MMX Voltage Settings:

When using the Pentium MMX CPU's, you should verify with your
vendor the correct voltage settings. These settings will work with either
ATX or AT powers supplies.

CPU Voltage J14 J15 J16 J17 J18 J19 J54 J55

MMX 3V off on off off off off on on
MMX 2.8V off off off on off off on on
MMX 2.6V off off on off off off on on

Heatsink Fan Power Source: J56

Pinout Assignment

1

+12V

2

Ground
