11 S1472-001-01 http://www.tyan.com
Reset Connector: J49
Pinout Assignment
1
Power Good
2 Ground
Turbo LED Connector: J51
Pinout Assignment
1
Cathode
2 Anode
Flash EPROM: J46
This jumper should be left at the factory default.
J46 1-2
Keylock Connector: J52
Pinout Assignments
1
Led Output
2 No Connect
3 Ground
4 Keylock
5 Ground
CMOS Resest/Password Reset: J38(Default off)
If you forget your CMOS password or need to reset the
CMOS registers, just power off the system and close
jumper J38 for five seconds. Then open jumper J38 and
power on the system. This will set the CMOS and password
back to the system default.
