(E) 56/62/72MX195
Chapter 13: Appendix
Video/Audio Terminals (continued)
HDMI ™ INPUT:
HDMI compliant (type A connector)
HDCP compliant
E-EDID** compliant
Suggested formats: 1080i, 480p, 480i, 720p
HDMI Audio: 2-channel PCM; 32/44.1/48 kHz sampling
frequency; 16/20/24 bits per sample
NOTE: This TV does not provide HDMI OUTPUT.
VIDEO/AUDIO OUTPUT (also for recording):
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent,
2.2 k ohm or less)
VARIABLE AUDIO OUTPUT:
0–300 mV(rms) (30% modulation equivalent,
2.2 k ohm or less)
G-LINK ™ and IR OUTPUT:
3 V(p-p), 3.5 mm mono socket (IR blaster cables supplied)
IEEE1394 INPUT/OUTPUT:
IEEE1394 compliant 4-pin
DIGITAL AUDIO OUTPUT:
Optical type
PC IN:
Mini D-sub 15 pin Analog RGB
PC AUDIO IN: 3.5 mm stereo mini jack
RJ-45 port:
Dimensions
56MX195: Width: XXX inches (XXX mm)
Height: XXX inches (XXX mm)
Depth: XXX inches (XXX mm)
62MX195: Width: XXX inches (XXX mm)
Height: XXX inches (XXX mm)
Depth: XXX inches (XXX mm)
72MX195: Width: XXX inches (XXX mm)
Height: XXX inches (XXX mm)
Depth: XXX inches (XXX mm)
Weight
56MX195: XXX lbs (XXX kg)
62MX195: XXX lbs (XXX kg)
72MX195: XXX lbs (XXX kg)
Supplied Accessories
• Two dual-wand IR blaster cables
• Remote control with two size “AA” alkaline batteries
• Owner’s Manual (this book)
Optional Stands:
56MX195: STxxxx
62MX195: STxxxx
72MX195: STxxxx _________
** E-EDID = Enhanced-Extended Display Identification
Specifications
NOTE:
• This model complies with the specifications listed below.
• Designs and specifications are subject to change without notice.
• This model may not be compatible with features and/or specifications that may be added in the future.
Television System
NTSC standard
ATSC standard (8VSB)
Digital Cable (64 QAM, 256 QAM; in-the-clear, unencrypted*)
*Encrypted channels can be viewed on this TV
using a CableCARD.™ See page 12 for details.
Channel Coverage
VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mid band (A-8 through A-1, A through I)
Super band (J through W)
Hyper band (AA through ZZ, AAA, BBB)
Ultra band (65 through 94, 100 through 135)
Power Source
120 V AC, 60 Hz
Power Consumption
XX W (average)
XX W in standby mode (using a CableCARD
™ )
XX W in standby mode (without a CableCARD ™ )
Audio Power
XXX W + XXX W
Speaker Type
Main: Two XXX-inch (XXXcm) round
Tweeter: Two XXX-inch (XXXcm) round
Video/Audio Terminals
S-VIDEO INPUT:
Y : 1 V(p-p), 75 ohm, negative sync.
C : 0.286 V(p-p) (burst signal), 75 ohm
VIDEO/AUDIO INPUT:
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent,
22 k ohm or greater)
ColorStream ® (component video) HD INPUT:
Y : 1V(p-p), 75 ohm
PR: 0.7 V(p-p), 75 ohm
PB : 0.7 V(p-p), 75 ohm
AUDIO: 150 mV(rms), 22 k ohm or greater
Suggested formats: 1080i, 480p, 480i, 720p
NOTE: This TV does not provide ColorStream HD OUTPUT.
