15
Chapter 4
VIDEO ADJUSTMENT
Video OSD Screen
NTSC 15.7K 60.2
VER XGA-KDC45-5100
1. Each time, when pressing the menu key, the screen will show as
above. You can see the 3mark, that means the selected item
Then you can change the setting through + or -.key.
2. Pressing Sel key to move the arrow down or up. If the selected
item has many option to choose, press – or + to enter into the
sub-menu.
3. Then move Sel key to item you want to change, the item will be
highlighted with red characters, then press – or + to change the
value.
4. If you finish the setting, press the MENU to key to the main OSD,
then repeat the item 2 and 3.
The OSD Main Screen
Brightness adjustment
§ Adjust the screen brightness value. The range if from 0 to 99.
Contrast adjustment
§ Adjust the screen contrast value. The range is from 0 to 127
3
Brightness
- Adjustment +
49
