Chapter 3, Djusting the monitor – Tote Vision LCD-1700VRZ User Manual
Page 12
11
CHAPTER 3
A
DJUSTING THE MONITOR
VGA OSD main screen
1. Each time, when pressing the menu key, the screen will show as
above. You can see the 3mark that means the selected item.
Then you can change the setting through + or -.key.
2. Pressing the Sel key to move the arrow down or up. If the selected
item has many option to choose, press – or + to enter into the
sub-menu.
3. Then move the Sel key to item you want to change , the item will
be highlighted as red characters, then press – or + to change the
value.
4. If you finish the setting, press the MENU to key to return to the
main OSD, then repeat the item 2 and 3 to do the changes you
want
1024x768 48.5K 60.2
VER XGA-KDC45-5100
Auto Adjustment
- Execute +
3
