Peripheral Equipment

193

The TANDBERG codec contains a DVI-I plug that can transmit either digital DVI signals or
standard analog VGA signals, depending on what type of monitor is connected.

DVI Specifications
TANDBERG DVI-I follows the VESA Monitor Timing Standard v1.08, also knows as Display
Monitor Timing (DMT).

Analog

Horizontal
Frequency

Vertical
frequency

Pixel
Clock

800x600 @
75Hz

46.875kHz

75.00Hz

49.50MHz

1024x768
@ 60Hz

48.363kHz

60.004Hz

65.00MHz

Digital

800x600 @
75Hz

46.875kHz

75.00Hz

49.50MHz

1024x768
@ 60Hz

48.363kHz

60.004Hz

65.00MHz

DVI-I Video resolution supported in F1 and above



Supported DVI cables:
TANDBERG supports DVI-D Single-Link, DVI-A and DVI-I Single-Link format cables.

DVI-D cables transmit digital T.M.D.S. signals, DVI-A cables transmit analog VGA signals and
DVI-I cables can transmit either digital or analog signals.

It is possible to extend existing DVI cables by the use of extension cables. The maximum cable
length however, is 5 meters. Going beyond that may result in quality loss.

DVI-I - Combined Analog and Digital Connector Pin Assignments:

Pin

Signal
Assignment

Pin

Signal
Assignment

Pin

Signal
Assignment

1

T.M.D.S.
Data2-

9

T.M.D.S.
Data1-

17

T.M.D.S. Data0-

2

T.M.D.S.
Data2+

10

T.M.D.S.
Data1+

18

T.M.D.S. Data0+

3

T.M.D.S.
Data2/4 Shield

11

T.M.D.S.
Data1/3 Shield

19

T.M.D.S.
Data0/5 Shield

4

T.M.D.S.
Data4-

12

T.M.D.S.
Data3-

20

T.M.D.S. Data5-

5

T.M.D.S.
Data4+

13

T.M.D.S.
Data3+

21

T.M.D.S. Data5+

6

DDC Clock

14

+5V Power

22

T.M.D.S. Clock
Shield

7

DDC Data

15

Ground (return
for +5V, HSync
and VSync)

23

T.M.D.S. Clock+

8

Analog Vertical
Sync

16

Hot Plug Detect

24

T.M.D.S. Clock-
