22
Configure the Wireless Connection (IK-WB16A-W only)
1. Check the SSID and wireless security currently set on your wireless access point (AP).
2. Go to IK-WB16A-W's Configuration > Wireless.
3. Set the SSID and wireless security consistent with the setting on your AP.
4. Select the Wireless mode as "Infrastructure".
5. Click Save. The Network Camera will reboot.
6. Wait for the live image to refresh in your browser. Then, unplug the power cable and
Ethernet cable from the Network Camera.
7. Replug the power cable to the camera. The Network Camera now operates in
wireless mode.
1. SSID, abbreviated from Service Set Identifier, is the name assigned to the wireless
network. The IK-WB16A-W's factory SSID setting is set to "default".
2. Select "Ad-Hoc" wireless mode if you want the IK-WB16A-W to communicate without
using an AP or wireless router.
3. Wireless networking has many security issues. It's very important that you define
effective wireless security policies that guard against unauthorized access to
important resources.
0100c5
POWER COLLISION LINK RECEIVE PARTITION 1 2 3 4 5
ADSL/Cable
/Switch
AP
4 3 2 1 WP S/R ES ET mic roS D
NOTE
For further setup, please refer to user's manual on the CD-ROM.
