4 Software Operation MIX 56 User Manual
4-8 Telect, Inc. 122188-10 A0
Low-Speed Configuration Screen
* Type is an inactive field when “Signal Type” is “T1.” To active this field “Signal Type” must be changed to
“Mixed, T1’s and E1’s.”
Alarm Thresholds Screen
These setting values are specified in Telcordia GR-820-CORE.
* This is not an active field; it only displays whether redundancy switching is “Normal” (allowed to switch) or
“Locked” (redundancy switching is not allowed).
System Interfaces Screen
Field Default Setting
Channel # “1”
Name “Low Speed 01”
Type T1 *
Interface NI
Line Code “B8ZS”
Line Build Out “0–110 ft”
State “Disabled”
Field Default Setting (sec)
AIS, LOS, RAI, and OOF Alarm On “002”
AIS, LOS, RAI, and OOF Alarm Off “003”
Low Speed ES-15 min. Alarm On “065”
Low Speed ES-24 hr. Alarm On “648”
Low Speed SES-15 min. Alarm On “010”
Low Speed SES-24 hr. Alarm On “100”
High Speed ES-15 min. Alarm On “025”
High Speed ES-24 hr. Alarm On “250”
High Speed SES-15 min. Alarm On “004”
High Speed SES-24 hr. Alarm On “040”
Redundancy Switch Status “Normal” *
Field Default Setting
Baud Rate “9600”
Modem Detect Disabled
SNMP Read Name “public”
SNMP Write Name “private”
SNMP Trap Name Blank
SNMP Event Traps Enabled
Ping Address “0.0.0.0”
IP Address “0.0.0.0”
Subnet Mask “0.0.0.0”
Gateway “0.0.0.0”
Trap 1, 2, 3, 4, 5, 6 “0.0.0.0”
Duplex “half”
