Tripp Lite 220/380V User Manual
Page 48
4
.
SU80K3/3PM, SU100K3/3PM, SU100K3/3INTPM and SU120K3/3PM Models
• Single Loop Connection (one input source used)
•
Double Loop Connection (two input sources used)
Note: cables labeled “1B”, “2B” and “3B” from the Single Loop Connection diagram
are removed.
Input
Output
Battery
Ground
Battery
Cabinet Ground
Battery
Cabinet Ground
Input
Reserve
Output
Battery
Ground
