4 MS-SVN015-EN
Typical Installation
Note: For models MCX 042, MCX 048, MCX 060
there are only two styles of installation: under ceiling and low wall
Ceiling
mounted
Outdoor unit
Indoor unit
Floor mounted
Return air grille contains air filter
Refrigerant tubing/wiring
Drain
Return air grille
contains air filter Supply air grille
Adjustable louvers direct air
Supply air grille
Adjustable louvers direct air
Low wall mounted
