DIMENSIONAL DATA
NOTE
1) DIMENSIONS : MILIMETERS [INCHES]
25.4 MM. = 1 IN.
MODEL
CONN. SIZES
LIQUID
SUCTION
TYPE
CONNECTIONS.
A
B
C
D
IN.
(MM.)
IN.
(MM.)
EACH
IN.
(MM.)
MCX042GB/G1
MCX048GB/G1
BRAZED
BRAZED
3/8 (9.5)
3/8 (9.5)
7/8
(22.2)
1-1/8 (28.6)
71.81
(1824.0)
64.13
(1629.0)
15.76
(400)
8
MCX060GB/G1
BRAZED
3/8 (9.5)
1-1/8 (28.6)
81.65
(2074.0)
73.98
(1879.0)
23.64
(600)
8
OUTLINE DIMENSIONS
MCX042-060GB (EXPORT 50 Hz)
MCX042-060G1 (EXPORT 60 Hz)
Dimensional Data
