Dimensional Data
OUTLINE DIMENSIONS
MCX512-536GB (EXPORT 50 Hz)
MCX512-536G1 (EXPORT 60 Hz)
MCX512GB/G1
MCX518GB/G1
MCX524GB/G1
DIMENSIONAL DATA
MODEL
CONN. SIZES
TYPE
A
B
C
LIQUID
SUCTION
CONNECTIONS.
IN.
(MM.)
IN.
(MM.)
EACH
1/4 (6.4)
1/2 (12.7)
42.28
(1074.0)
34.61
(879.0)
4
FLARED
3/8 (9.5)
5/8 (15.9)
51.13
(1324.0)
44.45
(1129.0)
4
FLARED
MCX530GB/G1
3/8 (9.5)
5/8 (15.9)
61.97
(1574.0)
54.29
(1379.0)
6
FLARED
MCX536GB/G1
3/8 (9.5)
3/4 (19.0)
61.97
(1574.0)
54.29
(1379.0)
6
FLARED
NOTE
1) SUCTION AND LIQUID LINES HAVE FLARE TYPE CONNECTIONS.
2) DIMENSIONS : MILIMETERS [INCHES]
25.4 MM. = 1 IN.
