Jumpers
3-2
3.1 Jumpers
Table 3–1 shows the function of each jumper on the EVM.
Table 3–1. Jumper/Function Reference
Reference
Designator
Setting/Pin Function Default Subsection
JMP1 1 to 2 Short R1 for IDAC0 output Disconnected 3.1.1
JMP2 1 to 2 Short R2 for IDAC1 output Disconnected 3.1.2
JMP3 1 to 2 Connect I 2 C SDA signal Disconnected 3.1.3
JMP4 1 to 2 Connect I 2 C SCL signal Disconnected 3.1.4
JMP5 1 to 2 Onboard AV
DD
1–2 3.1.5
2 to 3 External AV
DD
JMP6 1 to 2 Onboard DV
DD
1–2 3.1.6
2 to 3 External DV
DD
J7 1 AGND 1–2 3.1.7
2 REF IN–
3 VDAC1
4 REF IN+/REFOUT
5 Open
6 AV
DD
J16 1 Memory A14 RAM 3.1.8
2 MSC1211 A15
1–3, 2–4, 5–6
3 MSC1211 A14
4 Memory A15
5 Memory /WE
6 MSC1211 /WE
