Unpacking the MSC1211EVM
2-2
2.1 Unpacking the MSC1211EVM
After unpacking the MSC1211EVM kit, check to make sure you received all of
the items listed here:
- MSC1211EVM board
- 9V “wall–wart” power supply
- 9-pin, D-sub, male-female serial cable
- This user’s guide
- Software CD-ROM
2.2 Default Configuration
Although much of the MSC1211EVM operation is controlled by the host PC,
some configuration must be done directly on the board, using four jumpers
(shorting blocks). The MSC1211EVM is configured at the factory, as shown in
Table 2–1.
Table 2–1. Factory Jumper Settings
Jumper identifier Description Default Setting
JMP5 Analog power supply source 1–2
JMP6 Digital power supply source 1–2
J7 Internal Reference Select 1–2
For more information about the jumpers, see section 3.1.
