2.9 POWER FACTOR
Non
PFC
PFC
All models
0.65
0.98
Table 2-3 Power Factor
2.10 EFFICIENCY
Better than 85%
2.11 STORED ENERGY
Less than 0.3 Joules all models
2.12 STABILITY
0.2% TO 300 Hz. For higher repetition rates, consult factory
2.13 PULSE TO PULSE REPEATABILITY
±0.2% TO 300 Hz. For higher repetition rates, consult factory
2.14 TEMPERATURE COEFFICIENT
100ppm per ºC
2.15 AMBIENT TEMPERATURE
Storage -40 to +85ºC. Operating -20 to +45ºC
2.16 HUMIDITY
90%, non-condensing
2.17 PROTECTION
The power supply is protected against Open Circuits, Short Circuits, Overloads and Arcs
2.18 AGENCY APPROVALS
500A/102A/152A are approved to UL 60601-1 and IEC 60601-1, Class I. 202A pending
approvals
.
2.19 TRANSIENT LINE PROTECTION
Meets requirements of IEC 801-4, 801-5
2.20 ESD
All Remote Control Functions meet requirements of IEC 801-2
2.21 NOTE FOR PFC UNITS
When High Voltage is enabled by using either the “HV Enable” Line or deactivation of
the “Inhibit” Line the power supply will reach normal operation mode (and therefore all
other published specifications) within 50 ms.
