CHAPTER 2 SPECIFICATIONS
2.1 AVERAGE CHARGING RATE
500J/s, 1000J/s, 1500J/s, 2000J/s at rated Output Voltage
2.2 PEAK CHARGING RATE
550J/s, 1100J/s, 1650J/s, 2200J/s at rated Output Voltage
2.3 NUMBER OF MODELS IN SERIES
12 Standard (others at extra cost)
2.4 STANDARD VOLTAGE RANGES
1kV, 1.5kV, 2kV, 3kV, 4kV, 5kV, 5kV, 10kV, 15kV, 20kV, 30kV and 40kV. All models
continuously variable from 0 to 100% of rated output voltage.
2.4.1 LINEARITY
Linear to within 1% of full scale.
2.4.2 ACCURACY
1% of rated.
2.5 POLARITY
Available as fixed Positive or Negative
2.6 HIGH VOLTAGE ASSEMBLY
Insulating Medium/Cable
Voltage Medium Output
Cable
1kV to 6kV
Air
Coax. RG58
10kV to 40kV Oil
12 AWG, HV Silicon
Table 2-1: High Voltage Cable
2.7 INPUT CONNECTOR
VDE, UL approved.
2.8 INPUT CHART
Input Voltage selective by Terminal block position
Input Voltage (VAC)
Current (No PFC)
Current (PFC)
Nameplate
Range
Design
Range
500A
102A 152A 500A
102A
152A 202A
230
50/60Hz
180-253
50/60Hz
5A 10A 14.5A
3.5A
6.6A 10A
13.5
115
50/60Hz
90-140
50/60Hz
10A 20A 30A 7A
−
−
−
*Note: Input current ratings given are maximum when output Repetition Rate is
=>10Hz Consult Factory if model used at less than 10Hz.
Table 2-2: Input Voltage Chart
