1 external dimensions, Toshiba, Slide-in option card – Toshiba 1500 Plus User Manual
Page 29
TOSHIBA
30%
45%
60%
75%
90%
Overload
+
-
X
On Line
AC Input
Fault
Replace Battery
Backup
X
1500
SERIES
1000VA ON-LINE UPS
8.00
10.00
Input power
cord connector
Fuse
Computer
Interface
Connector
Output
Receptacles
Air Vents
20.38
9.0
External Dimensions/Shipping Weights/Panel Layout
9.1
External Dimensions
Front
View
Rear
View
Side
View
Run/Stop
switch.
0: Stop
1: Run
9 - 1
Slide-in
Option
Card
