84
HMX96 (E/F) Web 213:276
Chapter 9: Appendix
Specifications
Note:
• This model complies with the specifications listed
below.
• Designs and specifications are subject to change
without notice.
• This model may not be compatible with features and/or
specifications that may be added in the future.
Television System
NTSC standard
ATSC standard (8VSB)
Digital Cable (64 QAM, 256 QAM; in-the-clear,
unencrypted*)
Channel Coverage
VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mid band (A-8 through A-1, A through I)
Super band (J through W)
Hyper band (AA through ZZ, AAA, BBB)
Ultra band (65 through 94, 100 through 135)
Power Source
120 V AC, 60 Hz
Power Consumption
215 W (average)
28 W in standby mode (using a CableCARD
™ )
24 W in standby mode (without a CableCARD ™ )
Audio Power
10 W + 10 W
Speaker Type
Main: Two 2-3/8 × 4-3/4 inches (6×12 cm) round
Tweeter: Two 1-5/16 inches (33 mm) round
Video/Audio Terminals
S-VIDEO INPUT:
Y: 1 V(p-p), 75 ohm, negative sync.
C: 0.286 V(p-p) (burst signal), 75 ohm
VIDEO/AUDIO INPUT:
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent, 22 k
ohm or greater)
ColorStream ® (component video) HD INPUT:
VIDEO:Y: 1V(p-p), 75 ohm
P R : 0.7 V(p-p), 75 ohm
P B : 0.7 V(p-p), 75 ohm
Suggested formats: 1080i, 480p, 480i, 720p
AUDIO: 150 mV(rms), 22 k ohm or greater
HDMI ™ INPUT:
HDMI compliant (type A connector)
HDCP compliant
E-EDID** compliant
Suggested formats: 1080i, 480p, 480i, 720p
HDMI Audio: 2-channel L-PCM; 32/44.1/48 kHz
sampling frequency; 16/20/24 bits per sample
and Dolby Digital
VIDEO/AUDIO OUTPUT (also for recording):
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent,
2.2 k ohm or less)
VARIABLE AUDIO OUTPUT:
0–300 mV(rms) (30% modulation equivalent, 2.2 k
ohm or less)
DIGITAL AUDIO OUTPUT:
Optical type
G-LINK ™ :
3 V(p-p), 3.5 mm mono socket (IR blaster cables
supplied)
PC IN:
Mini D-sub 15 pin Analog RGB
PC AUDIO IN: 150 mV(rms), 22 k ohm or greater
RJ-45 port: Standard Ethernet (RJ-45)
Dimensions
50HMX96: Width: 47-3/16 inches (1,199 mm)
Height: 30-11/16 inches (780 mm)
Depth: 16-5/8 inches (422 mm)
56HMX96: Width: 52-3/8 inches (1,330 mm)
Height: 33-3/4 inches (857 mm)
Depth: 18-3/8 inches (467 mm)
Weight
50HMX96: 63.9 lbs (29.0 kg)
56HMX96: 72.1 lbs (32.7 kg)
Operating conditions
Temperature: 41ºF–95ºF (5ºC–35ºC)
Humidity: 20–80% (no moisture condition)
Supplied Accessories
• Remote control with two size “AA” alkaline batteries
• Dual-wand IR blaster cable
• Installation Guide
• Operating Guide (this book)
• TV Guide On Screen
™ Interactive Program Guide
Optional Stands
50HMX96: ST 5076
56HMX96: ST 5676
* Encrypted channels can be viewed on this TV using a
CableCARD.
™ ( - Installation Guide).
** E-EDID = Enhanced-Extended Display Identification
