58
1 103 7035 Base frame 1
2 103 7038 Front foot 1
3 103 7039 Rear foot 1
4 203 7020 Upright tube, (incl. 69) 1
5 203 7022 Handle bar, L (40,58,61,69) 1
6 203 7021 Handle bar, R (40,58,61,69) 1
7 343 7019 Axle support 1
*8 653 7023 Spring knob 2
9 203 7024 Swivl tube (incl. 64) 2
10 363 7005 Pedal, pair 1
11 103 7037 Pedal tube, left (incl. 64) 1
13 233 7013 Computer 1
14 103 7036 Pedal tube, right (incl. 64) 1
15 403 7018 Mains cable/transf., EUR 1
- 403 7019 M. cable/transformer,USA 1
16 203 7023 Fix handlebar (incl. 70,71) 1
17 533 7048 End cap 3
*18 M8 DIN 125 Washer 12
*19 M8 DIN 127 Spring washer 16
*20 M8 DIN 1587 Cap nut 4
*21 M8x90 DIN 603 Screw 4
22 533 9007 Rear foot cover 2
23 403 7024 Sensor wire 1
*24 M8x15 ISO 7380 Screw 6
*25 M8 DIN 440 Washer M8 OD 28mm 2
*26 M6x45 DIN 603 Screw 4
*27 M6 DIN 125 Washer 4
*28 M6 DIN 127 Spring washer 4
*29 653 7028 Knob dawl 4
30 M5x10 DIN 7985 Screw 2
31 M8x40 ISO 7380 Screw 2
32 403 7022 Computer wire 1
33 M10 DIN 125 Washer 2
34 12 DIN 471 Clip C12 2
35 523 504 84 Bearing 2
36 303 7003 Flywheel (incl. 33-35,37,39) 1
37 343 7021 Flywheel axle 1
38 M6x12 DIN 933 Screw 3
39 653 7026 3/8” Wh nut 2
40 533 7045 Plastic insert 2
41 643 7001 Carge spring 1
42 513 7001 Bracket (incl. 43, 44) 1
43 523 409 85 Bearing 4
44 17 DIN 417 Clip C17 3
45 M8x16 DIN 933 Screw 2
46 433 7005 Turning pedal, right 1
47 403 1026 Magnet 1
48 443 7003 Belt 1
49 M6x18 DIN 933 Screw 4
50 503 7011 Safe bracket 1
51 263 7007 Pulley (incl. 47) 1
52 343 7020 Axle for pulley 1
53 M6 DIN 985 Nylock nut 4
54 433 7006 Turning pedal, left 1
55 M3x8 DIN 7985 Screw 2
56 523 7014 Spacer sleeve 3
57 503 7015 Sensor bracket 1
58 213 7008 Handle grip, pair 2
59 173 7014 Chain cover, right 1
60 173 7013 Chain cover, left 1
61 533 7047 Handlebar end cap 2
62 533 7041 Turning plate cover 2
63 533 7042 Front foot cover 2
64 523 9006 Bearing 8
65 653 7025 Washer 2
66 M8x20 ISO 7380 Screw 4
68 343 7018 Pedal tube shaft 2
69 533 7044 Plug axle support 6
70 213 7010 Fix handlebar grip, pair 1
71 533 7049 Fix handlebar end cap 2
72 M5 DIN 985 Nylock nut 4
73 M5 x70 DIN 932 Screw 4
74 M8x12 ISO 7380 Screw 4
75 M5 DIN 125 Washer 4
76 M12 DIN 934 Nut 1/2” 8
77 M14 DIN 127 Spring washer 1/2” 4
78 533 7050 Plastic Sleeve 8
79 513 7002 Support bar 1
80 503 7013 Coil back bracket 1
81 503 7014 Coil bracket 1
82 403 7023 El. magnet 1
84 453 9002 Bottle 1
85 592 9002 Rack 1
86 M5x10 DIN 7985 Screw 2
- 423 0067 TUNTURI-logo 2
- 553 7005 Assembly kit (incl *) 1
- 583 7009 Owner’s manual 1
