background image

7

Battery Connection (Standard)

Choose the Basic Connection if you are running light hand tools or other small appliances for a brief
period of time (see Diagram 8, p. 47. Note: 8.1 is the alternator; 8.2 is the vehicle battery ground;
8.3 is a 12V vehicle battery; and 8.4 is the fuse)
. Choose the Advanced Connection if you are using
your APS to power heavy loads for extended periods of time (see Diagram 9, p. 47. Note: 9.1 is the
alternator; 9.2 is a battery isolator; 9.3 is the vehicle battery ground; 9.4 is a 12V vehicle battery;
and 9.5 is the fuse)
. This connection incorporates a battery isolator and separate battery system to
provide battery power to your APS while preventing it from draining your vehicle's battery. Note:
Depending on your application, you may require more than one 12V Deep Cycle Battery.

Caution: Never operate your APS from an alternator without a battery connected as show in Diagrams 8 and 9, p.47

Battery Connection (Vehicular)

Single 12V Battery Connection

(See Diagram 5, p. 46. Note: 5.1 is the fuse.)

Multiple 12V Battery System Connection (in Parallel)

(See Diagram 6, p. 47. Note: 6.1 is the fuse.)

Multiple 6V Battery System Connection (in Series)

(See Diagram 7, p. 47. Note: 7.1 is the fuse. Also, the connection will combine to provide
12V DC).

• Connect your APS's positive DC Terminal directly to a fuse near
your battery.

UL recommends that you install a recognized UL component fuse block and fuse within 18 inches of
the battery. The fuse should be rated a minimum of 100 amps. (See Figures 5, 6 and 7 for
recommended connection).

• Use the SHORTEST and HEAVIEST GAUGE battery cabling.

Use #4 cabling for DC cable lengths up to 10 feet. Use #2 cabling for lengths up to 16 feet. Shorter
and heavier gauge cabling limits DC voltage drop and allows for maximum transfer of current.*

* APS models are capable of delivering a much higher wattage output for brief periods of time. Therefore the wiring should
be configured to handle this brief high-current potential draw. Even though APS models are high-efficiency converters of
electricity, their rated output capacities are limited by the length and gauge of the wires running from the battery to the APS
.
