Parts Section 5-7
TRACTOR MOUNT KIT - HYDRAULICS, 2WD, 4WD
ITEM PART NO. QTY. DESCRIPTION
1 34064 1 ADAPTER 1 1/4” X 1”
2 06500012 1 HOSE,1 1/4 x 90 (1 1/4 FJX 45 x 1 1/4 90) 90
3 34068 1 ELBOW 1 1/2MP X 1 1/4MOR
4 34069 1 BALL VALVE 1 1/4”
5 34067 2 NIPPLE 1 1/4” X 1 1/4”
6 06500123 1 HOSE,1 1/4x77(24FLGx1 1/4FJ)
7 06500124 1 HOSE,1x241(1MJx1 1/4FJX)
8 06506000 1 HOSE 1” X 75”
9 06500011 1 HOSE 1” X 176”
10 TF4852 6 FLANGE KIT #20
11 34075 2 CLAMP KIT 1”
12 34626 2 BRACKET, TUBE / CLAMP
13 34076 2 CLAMP KIT 1”
14 24849 2 SPACER, 7/8 ID X 1-1/4 OD X 5/8
15 06503000 1 ADAPTER 10RB X 1-1/4 MJ
16 34117 1 ELBOW 1”MORB X 1”MJIC90
17 21644 4 CAPSCREW 3/8” X 5”
18 22016 4 FLATWASHER 3/8”
19 21988 2 LOCKWASHER 3/8”
20 6T2665 2 STAR LOCKWASHER 3/8”
21 21625 4 HEX NUT 3/8”
22 34115 2 SOLENOID BRACK VALVE
23 33555 2 ADAPTER 1”MORB X 1”MJIC
24 34161 1 HOSE 1” X 101”
25 34162 1 HOSE 1” X 98”
27 TF4868 1 SWIVEL 1” MP
28 23283A 1 UNION BLOCK 1”
29 22018 1 FLATWASHER 1/2”
30 21990 1 LOCKWASHER 1/2”
31 21725 1 HEX NUT 1/2”
32 34635 1 HOSE 1” X 68”
33 06500036 1 HOSE,1 x 150(1FJX x 1MJ)
34 23172 1 MOTOR ( M365-1 1/2 GEAR)
35 06500086 1 HOSE 1” X 33”
36 06500087 1 HOSE 1” X 40”
38 22680 2 MOTOR 2”
39 6T3200 2 SPLIT HOSE
40 23568 4 HOSE CLAMP
41 6T1823 24 ZIP TIE 14” LG
42 6T1822 8 ZIP TIE 8” LG
44 * REF HYDRAULIC TANK - REFER TO MAIN FRAME PARTS
45 * REF MAIN FRAME - REFER TO MAIN FRAME PARTS
46 * REF PUMP - REFER TO MAIN FRAME PARTS
47 * REF DECK - REFER TO COMMON SECTION, DECK PARTS
48 06503024 1 ADAPTER,1 1/4 MJ x 24 FLG
49 TF4854 2 FLANGE KIT #24
NOTE:Band hoses together with zip ties wherever loose. Where hoses
may contact the frame or other edges, wrap with split hose and
secure with hose clamps or zip ties.
12-18-02
