SPECIAL SOUND FEATURES
15 15 15
Dolby Digital
Dolby Digital is available from DVD players, some games console players, etc. These must be connected using
a Scart or phono lead for the picture AND an optical or a coaxial cable for the sound see page 23.
Dolby Digital
Adjustments
The DVD is connected to the TV using phono leads to
the COMPONENT VIDEO INPUT or a Scart lead to
Scart 3, and an optical or coaxial cable to the
optical/coaxial sockets, DA-1 or DA-2.
The Digital input in the AV CONNECTION
menu (see page 22) is set to EXT3 if Scart 3 is used
or EXT4 if the DVD is connected to COMPONENT
VIDEO INPUT.
If external front speakers are
connected the external switch (found on the back of
the TV) is set to EXT.
Rear speakers are connected and the Rear
Speaker option in the Surround set up menu
is set to YES .
Set the volume and balance of the front speakers to your preference.
Play a Dolby Digital source and press the M button on the TV’s remote control.
The title, e.g. Dolby Digital 3/2, is an indication of the channels available from
your current sound source, see the table.
To adjust the levels, use the P or Q button to select the centre and two rear
speakers in turn. Press either the S or Rbutton to adjust. The number of
adjustable speakers will depend upon the signal received from the DVD player.
To cancel the test press the EXIT button.
1
1
2
3
4
2
From the FEATURE MENU select Surround set
up .
With Delay time highlighted, use the S or R button
to change the setting to a value that suits you.
Press EXIT when you have finished.
1
2
3
3
4
Dolby Digital
1/0 = Centre speaker only.
2/0 = Front Left and Front Right only.
2/1 = Front Left and Front Right +
Rear Left and Rear Right combined.
2/2 = Front Left and Front Right +
Independent Rear Left and Independent Rear Right.
3/0 = Front Left and Front Right and Centre.
No Rear Speakers.
3/1 = Front Left and Front Right and Centre +
Rear Left and Rear Right combined.
3/2 = Front Left and Front Right and Centre +
Independent Rear Left and Independent Rear Right.
Arrange the speakers around your normal viewing
positions (as shown on page 5) and then make sure
that the TV is set up as follows: DELAY TIME…
If you sit a long way from the TV and close to the rear
speakers the sound from the rear will reach you before
the sound from the front. You can use a higher setting
in the
Delay time option to restore the correct balance.
If rear speakers are NO
T
selected in the
Surround set up
menu, you will not hear any sound
from your rear speakers.
!
If the DVD playing is recorded in Dolby P
ro Logic,
i.e. 4 channel stereo (front left, front right, centre and
rear) the TV will detect the 4 channels.
In this instance, when the Surround T
est Mode is
run the TV will cycle through the four channels in use.
In order to get full Dolby Digital, the D
VD
player must be connected using the coaxial or
optical links.
!
Alternatively, use the
Test mode in the
SURROUND SET UP
menu.
☛
