Tation hardware, 2 station hardware – Toshiba S20LP User Manual
Page 6
5
6
F
3
B
0
3
5
6
1.2 Station hardware
•
Overview
PU245N
RUN FLT BAT
ERUN ET/R EACC
SRUN SONL SACC
STNH
STNL
LINK
PROG
OTR1
OTR2
10BASE-T
Status LEDs for
Ethernet Port
Status LEDs for
S20LP Port
DIP switches
for CPU
For S20LP Port
Station number
setting switches
Transmission
cable connectors
LOADER port
For Ethernet Port
T2N include of S20LP Port
